Quick Details

  • Condition: New
  • Flow: 55-200 L/Min
  • Working Pressure: Normal Pressure
  • Place of Origin: Chongqing, China (Mainland)
  • Brand Name: ZHONGNENG
  • Model Number: TYB-100
  • Usage: Lubricant Oil
  • Voltage: 380V
  • Power(W): 12-24KW
  • Dimension(L*W*H): 238*150*210 CM
  • Weight: 800-1600KGS, 80Kg
  • Certification: CE, ISO9001
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Model: TYB-10
  • Capacity: 600 liters per hour
  • usage: waste oil purification
  • Water content: <100PPM
  • Cleanness: < grade 6 NAS
  • Power supply: 380V, 50Hz, 3phase
  • outer size: 700* 570*550mm
  • MOQ: 1Set
  • Color: Green or as you requested

Packaging & Delivery

Packaging Details wooden case
Delivery Time 15 days

            TYB Series Coalescence-Separation Oil Purifier Machine, Waste Oil Dehydration Machine

Application:
This machine integrates coalescer and separator Filter elements, high efficiency demulsification and dehydration into one body. This machine, which can remove large of water without heating, creates the fastest dehydration speed in domestic at present.

This machine can quickly separate water from the oil, which even contains half water, to attain cleanness of NAS six grade, Convenient using with the go-cart model designed. This machine is suitable for treating light fuel oil with high water content.

Features:
1 TYB series purifier adopt special oil water separator which requires no heating offering more than 20 times dewatering efficiency over other types of purifiers.
2 As no heating is needed, the additives in the oil are well prevented from degradation or deterioration.
3 Easy-to-operate, water can be discharged online automatically without the presence of duty operators.
4 Low operation cost, 20%-40% lower than vacuum purifier, centrifugal purifier and filter press

5 Equipped with explosion proof device, make the whole processing of waste oil with low flash point becomes safe and reliable.



Technical parameters

ITEM

TYB-10

TYB-20

TYB-30

TYB-50

TYB-80

TYB-100

Flow Rate (L/H)

600

1200

1800

3000

4800

6000

Working pressure (Mpa)

≤0.3

Water content (PPM)

≤100

Cleanness (NAS)

≤Grade 6

Working noise Db(A)

≤70

Power supply

380V, 50Hz, 3Phase (As per clients’ request)

Nominal power (KW)

0.75

0.75

0.75

2.2

2.2

3

Weight (KG)

80

90

105

135

150

185

Size (MM)

L

700

700

700

850

800

1000

W

570

570

600

650

650

700

H

550

600

650

750

800

850

Dimensions will be changed if any special type required
